Option: Mechanical Flush Valve

When specified, Acorn will provide a code-approved Mechanical Flush Valve complete with exposed Lever Handle or Pushbutton, Vacuum Breaker, Tailpiece, and Elbow. All exposed parts include a chrome-plated finish.

-T Top supply Toilets and Urinals with -FV option are provided with an exposed Flushometer with an ADA Compliant Lever Handle.
*Typical Toilet Flush Valve models are provided by Sloan;
Toilets: 111 Series.
Urinals: Regal 186 Series.

-W Wall Supply Toilets and Urinals with -FV option are provided with a Through-Wall Mechanical Pushbutton and concealed Mechanical Flush Valve (Not suitable for ADA compliance). Wall thickness and type are required to determine the Pushbutton “L” Dimension.
*Typical Flush Valve models are provided by Sloan ;
Toilets: Regal 611 Series.
Urinals: 613 Series.

Lav-Toilet Combination Fixtures (Combys) with -FV option are provided with a Backsplash Mounted Through-Wall Mechanical Pushbutton and concealed Mechanical Flush Valve. Applies to Rear Mounted Combinations only (Not suitable for ADA Compliance). Wall Thickness and type are required to determine the pushbutton “L” Dimension. Mechanical Flushometer is not offered for -FA front Access or ADA Compliant Combination fixtures.
*Typical Flush Valve models are provided from ® Sloan;
Royal 603 Series.

*Note: Provided as reference only. Refer to the manufacturer for complete data. Subject to change without notice.
