Accessory: Tempering Valve for Point-of-Use Fixtures

The model ST7069, an ASSE 1070 and 1069 compliant Thermostatic Mixing Valve, is Lead-Free and ideal for delivering safe tempered water at the point-of-use fixture(s) such as sinks, baths, showers, or lavatories in residential, commercial, and institutional environments.

Key Benefits

• Install at point of use to temper water for sinks, baths, showers, and lavatories
• Brass and paraffin wax design eliminates unreliable and inconsistent performance of competitors’ bi-metal designs
• Accommodates up to 8 single temperature showers or 24 lavatories

This valve can deliver 12 GPM (45 LPM) @ 45 PSI (310 kPa) differential and accommodate up to 8 single temperature showers or up to 24 hand washing stations with 0.5 GPM (1.9 LPM) flow restrictors.

ST7069 Valve Features

• Lead-Free certified DZR brass body with corrosion-resistant and lead-free internal components.
• Integral cartridge-style checks with screens to prevent backflow and filter debris from entering the valve.
• Temperature adjustment is made using an Allen wrench and a locknut on the bonnet prevent unauthorized or accidental temperature adjustment.
• Commercial quality paraffin actuator provides repeatable, reliable performance.
• Lockable Brass ball valves are optionally available.
• IAPMO certified to ASSE 1069.
• IAPMO certified to ASSE 1070.
• IAPMO certified to CSA B125.3.

USED IN COMMERCIAL, INSTITUTIONAL, AND INDUSTRIAL APPLICATIONS
